FUOCO FISCHIATORE 3.6
WHISTLER 3.6 È DOTATA DI CAMBIO SHIMANO ALTUS 3X9 E FORCELLA AMMORTIZZATA SR SUNTOUR XCT-ATB CON PUNTI DI ATTACCO PER PARAFANGHI EVIDENZIAZIONE VISIVA E MIGLIORE PROTEZIONE: TUTTI I CAVI SONO INTEGRATI NEL TELAIO OPZIONE PER MONTARE PORTAPACCHI E PARAFANGO NONCHÉ ULTERIORI PUNTI DI FISSAGGIO SOTTO IL TUBO SUPERIORE PER ATTACCARE AD ESEMPIO UN SERRATURA PIEGHEVOLE
- Brand: MESSA A FUOCO
Ulteriori informazioni
MAKES SPORT COME NATURALLY
A WHEEL SIZE FITTING YOUR HEIGHT
With the WHISTLER, you get the ideal wheel size to suit your height and needs: The WHISTLER in sizes XL to M comes with 29" wheels. Size S and XS have 27,5" wheels.
RELIABLE BRAKING POWER AND INTEGRATED DESIGN
When faced with risky situations, you need a partner you can rely on. That is why we have equipped our WHISTLER with disc brakes to ensure consistent braking performance and optimal braking behaviour in all weather conditions. We route all cables through the down tube of the frame for better protection of the cables, durability and a clean look.
READY FOR YOUR RIDING REQUIREMENTS
To allow you to fully tailor your bike to your needs, you have mounting options for a pannier rack, mudguards, light and stand.
GEOMETRY
| XS | S | M | L | XL | ||
|---|---|---|---|---|---|---|
| SIZE | 34 | 38 | 42 | 46 | 50 | |
| SIZE (MM) | 340 | 360 | 420 | 460 | 500 | |
| HANDLEBAR WIDTH | 720 | 720 | 720 | 720 | 720 | |
| STEM LENGTH (MM) | 60 | 60 | 60 | 60 | 60 | |
| CRANKARM LENGTH | 170 | 170 | 170 | 170 | 170 | |
| SEAT POST LENGTH (MM) | 350 | 350 | 350 | 350 | 350 | |
| A | SEAT TUBE LENGTH (MM) | 340 | 360 | 420 | 460 | 500 |
| B | EFFECTIVE TOP TUBE (MM) | 549 | 574 | 606 | 636 | 666 |
| C | HEAD TUBE ANGLE (°) | 68 | 68 | 68 | 68 | 68 |
| D | EFFECTIVE SEAT TUBE ANGLE (°) | 74 | 74 | 74 | 74 | 74 |
| E | CHAINSTAY LENGTH (MM) | 440 | 400 | 450 | 450 | 450 |
| F | BOTTOM BRACKET DROP (MM) | 48 | 48 | 60 | 60 | 60 |
| G | HEAD TUBE LENGTH (MM) | 120 | 120 | 120 | 140 | 160 |
| H | FORK CONSTRUCTION HEIGHT (MM) | 497 | 497 | 515 | 515 | 515 |
| I | PRE-RAKED FORK (MM) | 42 | 42 | 51 | 51 | 51 |
| J | WHEELBASE LENGTH (MM) | 1079 | 1104 | 1155 | 1187 | 1220 |
| K | STACK (MM) | 605 | 605 | 630 | 649 | 667 |
| L | REACH (MM) | 375 | 400 | 425 | 450 | 475 |
